BWT-3818 4G Micro Cell
Description
Features
Specifications
Single-band, For Outdoor Scenarios
Based on the leading SoC solution, BWT-3818 is designed as one-box micro-cell eNB for low density but large coverage scenarios.
2T2R MIMO, up to 40W per channel, support larger coverage
Plug and play, easy to deploy
SON, self-organized, self-launched, self-optimized
Compact design with high integration
Nature cooling, low noise and green
IP65 for various harsh environment
| Protocol | LTE FDD/TDD | ||
| Frequency | B1/B3/B7, customized for other bands | ||
| Bandwidth | 5/10/15/20 MHz | ||
| Peak rate (20MHz) | FDD: DL 200Mbps (256QAM), UL 75Mbps (64QAM) TDD: DL 140Mbps (256QAM,SF2), UL 30Mbps (64QAM, SF1) | ||
| Maximum users | VoLTE user: 64 RRC active user: 128 RRC connective user: 384 | ||
| Multi input/output | 2T2R | ||
| RF power | 2×40W | ||
| Volume | < 17L | ||
| Weight | < 16kg | ||
| Power required | -48V DC | ||
| Consumption | < 350W |
